Specifiche
Nominal Diameter
26 mm (1 in)
Nominal Power Handling
100 W
Sensitivity
93 dB
Voice Coil Diameter
26 mm (1 in)
Winding Depth
1.7 mm (0.07 in)
Impedenza nominale
4 Ω
Continuous Power Handling
250 W
Frequency Range
2500 kHz – 20000 kHz
Diaphragm Material
Silk soft dome
Parametri
Fs
1000 Hz
Qes
1.14
Qts
0.86
Mms
0.35 g
Le
0.03 mH
EBP
877 Hz
Re
3.25 Ω
Qms
3.5
Sd
8 cm² (1.24 sq²)
Bl
2.5 Tm
d
32 mm (1.26 in)
Design
Cone Shape
Dome
Cone Material
Silk
Connection Type
Faston
Informazioni di montaggio e spedizione
Diametro totale
100 mm (3.94 in)
Baffle Cutout Diameter
77 mm (3.03 in)
Flange and Gasket Thickness
8 mm (0.31 in)
Shipping Units
12 pcs
Bolt Diameter
5 mm (0.2 in)
Bolt Circle Diameter
88 mm (3.46 in)
Depth
34 mm (1.34 in)
Net Weight
0.64 kg (1.41 lb)
