Specifiche
Nominal Diameter
165 mm (6.5 in)
Nominal Power Handling
80 W
Sensitivity
93 dB
Voice Coil Diameter
38 mm (1.5 in)
Winding Depth
6.5 mm (0.26 in)
Impedenza nominale
8 Ω
Continuous Power Handling
200 W
Frequency Range
80 Hz – 80 Hz
Former Material
Kapton
Magnetic Gap Depth
6 mm (0.24 in)
Parametri
Fs
66 Hz
Qes
0.32
Qts
0.31
Sd
135 cm² (20.93 sq²)
Xmax
1.8 mm (0.07 in)
Bl
8 Tm
Cms
0.7 mm/N
EBP
206 Hz
Re
5.9 Ω
Qms
6
Vas
17.7 dm³ (0.63 ft³)
η0
1.47 %
Mms
8.5 g
Le
0.18 mH
d
131 mm (5.16 in)
Design
Surround Shape
Doped fabric
Recommended Loading
Vented Box
Recommended Enclosure
10 dm³ (0.353 ft³)
Informazioni di montaggio e spedizione
Diametro totale
165.5 mm (6.52 in)
Baffle Cutout Diameter
142 mm (5.59 in)
Flange and Gasket Thickness
7 mm (0.28 in)
Shipping Units
6 pcs
Bolt Quantity
Bolt Circle Diameter
156 mm (6.14 in)
Depth
80 mm (3.15 in)
Net Weight
2.4 kg (5.29 lb)
Basket Material
Steel
Bolt Diameter
5 mm (0.2 in)
